12” Tower

Eurotruss plated support tower systems are integral to the Eurotruss Plated Truss Series 12” and 20.5” Box Truss.  Eurotruss offers two kind of support towers including our 12” tower. Which is capable of supporting 2000 lbs to a maximum height of 30 feet in a 4 tower configuration, 20 ft in a 2 tower configuration with the tower outrigger section fitted, or 15 feet as a single tower with the tower outrigger arms and section fitted. The support tower outriggers are designed to provide stability and rigidity to single or 2 tower systems.

Ground support towers will provide the necessary equipment to support a truss rig in venues where the flying points are either not strong enough, or not in the right place. Our ground support systems are manufactured to accommodate the strictest demands from the entertainment industry.

Sleeve sections are available in plate form to integrate with our 20.5” corner blocks. These sleeve plates will allow the corner block to be either corner blocks or sleeve blocks.

  • Steel bases on wheels with integrated long or short outriggers
  • Each base comes with 8 adjustable pads to level the tower
  • The hinge section uses our popular hinge set which is a tried and true method for tower assembly.
  • The top section rollers are made from high density materials
  • A tower erecting system is available for the plated versions of our towers.

Technical specifications

Max. Height
30 ft. (9,1 mtr)
Max. Loading
2.000 lbs (907 kg)
Tower Truss
12'' Box (30,5 cm. Box Truss)
